ActronAir Aspire LRE-100DS | URC-100DS 10.5kW Ultra Slim Low Profile Split Ducted System

SKU: LRE-100DS / URC-100DS / WC-03

10.2 kW Cooling | 12.0 kW Heating
ActronAir Aspire LRE-100DS | URC-100DS 10.5kW Ultra Slim Low Profile Split Ducted System
Indoor LRE-100DS | Outdoor URC-100DS

Wired Controller
Indoor 245mm height
Built In Drain Pump
Incorporated Drain Pump with 1000mm lift | Gold Coated Protection

5 Years Manufacturer’s Warranty

Or own it from $130.73 weekly for 6 months*

Or pay in slices, no interest ever

Or own it from $130.73 weekly for 6 months*

Or pay in slices, no interest ever

Model	Outdoor	URC-100DS
Model	Indoor	LRE-100DS
Operating Capacity	(1)(2) Cooling Capacity (kW)	10.20
	(1)(2) Cooling Capacity Range (kW)	2.30 ~ 11.61
	(1)(3) Heating Capacity (kW)	12.00
	(1)(3) Heating Capacity Range (kW)	2.70 ~ 12.90
Electrical Characteristics	(1)(4) Cooling Input Power (kW)	3.05
	(1)(4) Heating Input Power (kW)	3.00
	Standby Power (w)	10.80
Efficiency	(1)(2) EER / AEER	3.344 / 3.305
	(1)(3) COP / ACOP	4.000 / 3.952
	TCSPF Residential (Hot / Avg. / Cold)	5.615 / 5.003 / 5.185
	HSPF Residential (Hot / Avg. / Cold)	5.051 / 4.346 / 3.717
Power Supply		220 – 240V / 1Ph / 50Hz
Interconnecting Wire (mm2)		1.0 x 4
(7) Maximum Running Current (Full Load Amps)		21
(8) Rated Load Amps	Cooling	13.5
(8) Rated Load Amps	Heating	13.5
(9) Circuit Breaker (A)		25
IP Rating	Outdoor	IPX0
IP Rating	Indoor	IPX4
Indoor Unit Dimensions	Height (mm)	245
	Width (mm)	1200
	Depth (mm)	750
Indoor Weight	Net (kg)	40.5
Spigot Dimension	Supply – W x H (mm)	1027 x 178
	Return (Under) – W x H (mm)	1092 x 212
	Return (Rear) – W x H (mm)	1092 x 212
Airflow Volume	Turbo (l/s)	639
	High (l/s)	556
	Medium (l/s)	500
	Low (l/s)	417
	Silence (l/s)	139
External Static Pressure	Range (Pa)	0 ~ 160
Drainage Water Pipe Diameter (mm)		OD Ø25mm
Outdoor Unit Dimensions	Height (mm)	810
	Width (mm)	946
	Depth (mm)	410
Outdoor Weight	Net (kg)	75.2
Compressor Type		Inverter Single Rotary
Refrigerant Type		R32
Pre-Charge	Amount (g)	2600
Pre-Charge	Length (m)	20
Connections	Connection Type	Flared
	Liquid	Ø9.52
	Gas	Ø15.90
Maximum Piping	Length (m)	75
Maximum Piping	Height (m)	30
Minimum Piping	Length (m)	3
(5) Outdoor Sound Pressure Level @ 1m dB(A)		62
(6) Outdoor Sound Power Level dB(A)		68
Operating Range	Cooling °C	-15 ~ 50°
	Heating °C	-20 ~ 24°
	Dry °C	0 ~ 50°
Available Control Options (Sold Seperately)		WC-03 \| WTC-01 \| RC-02

With an ActronAir Aspire UltraSlim Series Ducted Split System, you can enjoy the best of both worlds – perfect climate control and energy efficiency. With a height of one of the lowest in its category, it is perfect for homes with limited installation space.

Incorporating DC technology, ActronAir’s UltraSlim Split Ducted range features inverter control and the ability to achieve superior operating efficiency, ensuring optimal comfort all year round.

Features

Indoor

Tailored for tight spaces

Easy Installation – Separable Design
ActronAir’s 17kW ducted system has been redesigned. The two-piece construction makes installation into space-constrained roof spaces easier than ever before, while still providing the same level of quality and performance that our customers expect. In addition, the increased airflow variability allows for greater flexibility in room layout, ensuring that you will get the most out of your new air conditioning unit.

Precise airflow
With its high static design, the UltraSlim delivers the required airflow to your space easily, unlike other systems that can struggle and take a lot longer to cool or heat your space.

The extras count
To avoid those annoying extra costs, the UltraSlim comes with many features our competitors don’t include, such as a built-in drain pump, remote on/off and fault alarm outputs for installation ease and efficiency.

Outdoor

Coated Coil Protection
The UltraSlim uses gold fin epoxy coated protection on its indoor and outdoor coils, which helps to reduce corrosion from the harsh Australian conditions, as well as assisting the defrosting process, thus improving heating efficiency.

DC Inverter Technology
The UltraSlim Ducted system uses ultra-energy-efficient DC, or direct current inverter technology in its inverter compressor resulting in improved efficiencies overall, along with optimal cooling performance.
