ActronAir Multi Elite MRC-135DS-5 13.5kW Gen D Air Conditioner Outdoor Unit Only

SKU: MRC-135DS-5

ActronAir Multi Elite MRC-135DS-5 13.5kW Gen D Air Conditioner Outdoor Unit Only
13.5 kW Cooling | 14.0 kW Heating | Part of a Multi System

  • 5 Maximum possible combination
  • Pipe Adaptors Included
  • Rotary Compressor
  • Coil Protection

5 Years Manufacturer’s WarrantyView Combination Matrix



Model MRC-135DS-5
Operating

Capacity

(1)(2) Cooling Capacity (kW) 13.5
(1)(2) Cooling Capacity Range (kW) 2.63 ~ 14.65
(1)(3) Heating Capacity (kW) 14.0
(1)(3) Heating Capacity Range (kW) 2.63 ~ 15.24
Electrical

Characteristics

(1)(4) Cooling Input Power (kW) 3.73
Power Consumption (w) 3730
(1)(4) Heating Input Power (kW) 3.16
Power Consumption (w) 3155
Efficiency
(1)(2) EER / AEER 3.619 / 3.561
(1)(3) COP / ACOP 4.437 / 4.353
TCSPF Residential (Hot / Avg. / Cold) 5.959 / 5.304 / 5.530
HSPF Residential (Hot / Avg. / Cold) 5.545 / 4.800 / 4.312
Multi

Head Connection

IDU Minimum 2
IDU Maximum 5
Power Supply 1Ph / 220-240V / 50Hz
Interconnecting Wire 3 Core + E
Maximum Running Current (Full Load Amps) 30
(8)

Rated Load Amps

Cooling 17.8
Heating 16.2
(9) Circuit Breaker (A) 32
IP Rating IPX4
Unit

Dimensions

Height (mm) 975
Width (mm) 980
Depth (mm) 415
Package

Dimensions

Height (mm) 1080
Width (mm) 1145
Depth (mm) 500
Weight
Net (kg) 91
Gross (kg) 106.4
Compressor Type Inverter Rotary
Starting Method DC Inverter Starter
Compressor Power Output (W) 13700
Refrigerant Type R32
Refrigerant Oil Type / Charge in ml ESTER OIL VG74 / 1400
Pre-Charge
Amount (g) 3600
Length (m) 5 x 10
Additional Refrigerant Charge (g/m) 12
Airflow Volume (l/s) 1361
Connections
Connection Type Flare Nut
Liquid 5 x Ø6.35
Gas 3 x Ø9.52 + 2 x Ø12.7
Maximum

Piping

Per Indoor (m) 35
Total System (m) 80
Lift per Indoor (Inc. in Max. Pipe) (m) 15
Minimum Piping per Indoor (m) 12
(5) Sound Pressure Level @ 1m dB(A) 63.5
(6) Sound Power Level dB(A) 72
Operating

Range

Cooling °C -15 ~ 50°
Heating °C -15 ~ 24°
Dry °C 0 ~ 50°

MultiElite multi-split system allows you to run up to five indoor units through a single outdoor unit. That’s smart, because it can save not only space, but also energy. And while its powerful enough to keep the whole home in air conditioned comfort, MultiElite’s DC inverter can also ramp right down to power a single room. MultiElite also allows you to pick the best solution for specific rooms, whether it’s a concealed bulkhead system, Mini-Cassette or the ever popular wall mounted systems.

Flexible installation options
The MultiElite system’s flexible piping capabilities allow for optimal placement of the outdoor unit, ensuring it fits seamlessly into your home’s design.

Smarter performance all round
From the sustainable R32 Refrigerant promoting a greener lifestyle to the energy-saving inverter system and the simplified design, everything about the MultiElite system is focused on efficiency, cost saving and above all, comfort.

Coated Coil Protection
The MultiElite uses gold fin epoxy coated protection on its indoor and outdoor coils, which helps to reduce corrosion from the harsh Australian conditions, as well as assisting the defrosting process, thus improving heating efficiency.

Designed to save both energy and money
With a host of cutting-edge features, including DC fan motors, DC rotary compressors, and programmable timers, our MultiElite ducted split system uses less power than ever before.

Keep calm and carry on with Quiet Mode
The whisper-quiet operation ensures a tranquil indoor environment, perfect for sleeping, as well as activities such as studying, reading, or working from home.

In a multiple room environment not everyone’s preferred temperature is the same. Our MultiElite allows for different temperatures in different rooms at the same time.

MultiElite multi split system is covered by a single 5 year warranty.*

ActronAir Multi Elite MRC-135DS-5 13.5kW Gen D Air Conditioner Outdoor Unit Only – Brochure

Description

13.5 kW Cooling
14.0 kW Heating

Serves 5 Indoor Units
